User Guide

DS50003629A - 1

Introducon

This user guide provides detailed information about using the Microchip Radio Test 3 tool (MCHPRT3) with

the Microchip PIC32CX-BZ3. The MCHPRT3 enables the user to evaluate and demonstrate the RF performance,

calibration and functionalities of the PIC32CX-BZ3.

Note: In this user guide, the MCHPRT3 tool with the PIC32 WBZ351 Curiosity Board is only shown as an

example.

The MCHPRT3 is intended for development purposes. Any production test must use either a third-party

production tool or users must develop their own production tool based on the MCHPRT3 CLI or DLL release.

Features

• DLL Version – DLL Information and Firmware Support Version

• COM PORT – COM Port Information and Conguration

• Baud Rate – 115200 (Default Value)

• RF Bluetooth

– Bluetooth Low Energy RF Parameter Conguration and Information

• RF ZB – Zigbee

RF Parameter Conguration and Information

• MAC Address Information and Conguration

• IB File – Read or Save Information Block (IB) File

• Calibration Information and Conguration

• GPIO Information and Conguration

For more details, refer to 4. Getting Started.

PIC32CX-BZ3 MCHPRT3 User Guide

PIC32CX-BZ3

User Guide

DS50003629A - 2

Table of Contents

Introduction ..........................................................................................................................................................................1

Features ................................................................................................................................................................................ 1

1. Quick References ..........................................................................................................................................................3

1.1. Hardware Prerequisites.....................................................................................................................................3

1.2. Software Prerequisites...................................................................................................................................... 3

1.3. Acronyms and Abbreviations............................................................................................................................3

2. Overview.........................................................................................................................................................................4

3. MPLAB X IDE HUT Code Programming Process ........................................................................................................6

4. Getting Started...............................................................................................................................................................8

4.1. Getting Started with MCHPRT3........................................................................................................................ 9

4.2. Getting Started with MCHPRT3 PIC32CX-BZ3 GUI ...................................................................................... 11

4.3. MCHPRT3 PIC32CX-BZ2 GUI Demonstration ...............................................................................................12

5. Document Revision History........................................................................................................................................30

Microchip Information....................................................................................................................................................... 31

The Microchip Website............................................................................................................................................... 31

Product Change Notication Service........................................................................................................................ 31

Customer Support.......................................................................................................................................................31

Microchip Devices Code Protection Feature............................................................................................................ 31

Legal Notice..................................................................................................................................................................31

Trademarks.................................................................................................................................................................. 32

Quality Management System.....................................................................................................................................33

Worldwide Sales and Service..................................................................................................................................... 34
